Take your Gen 2 Raptor to the next level with this Factory Race Series front upgrade kit, designed to deliver a high level of adjustability via Dual Speed Compression (DSC) adjusters and improved cooling efficiency through an all-new Recirculating Reservoir Bridge and finned remote reservoir.
This kit delivers the next level of off-road performance without sacrificing every day ride quality and comfort.
| Body | 3.0" Hard anodized aluminum |
|---|---|
| Reservoir | NEW, hard anodized extruded aluminum finned remote reservoir with NEW Recirculating Reservoir Bridge |
| Components | Hard anodized, CNC-machined 6061-T6 billet aluminum |
| Spring | 3.75" racing spring selected specifically for the Gen 2 Raptor, preset to level your stock Raptor front-to-rear |
| Shaft | 7/8" 17-4 H900 hard chrome plated stainless steel |
| Piston | Hard anodized 6061-T6 billet aluminum high flow race piston |
| Valving | Specific for Gen 2 Raptor to maximize performance and comfort |
| Bearing | Spherical, PFTE-lined, heat-treated steel |
| Adjustments | Dual Speed Compression (DSC) adjuster |
| Ride-height/spring preload ring | |
| Adjuster Type | DSC - Dual Speed Compression |
| Extended | 28.450 |
| Compressed | 20.600 |
| Travel | 7.850 |
| Top Mount | OEM |
| Bottom Mount | Eyelet |
